 | Requires 30% less footprint space |
| Fully Automatic Self-Calibration |
| One Touch Calibration |
| Easy Access Door |
| Splash Proof Keyboard and Display |
| Advanced Stabilization Software |
| Automatic Adjustable Environment Setting |
| Multiple Weighing UnitsGLP Compliance |
| Standard RS-232C allows bidirectional communication with PC |
| Standard Underhook |
| Quick Reference Card |
| Bundled with A&D's new WinCT Software |
|
|
GR-120 |
GR-200
|
GR-300 |
GR-202 |
||
|
Capacity |
120 g |
210 g |
310 g |
210 g (dual
range) |
||
|
Resolution |
0.0001 |
0
- 40 x .00001 (.01 mg)
40
- 210 x .0001 (1 mg) |
||||
|
Operating Temp |
5°C to 40°C (41°F to 104°F), 85% RH or less (No condensation) |
|||||
|
Display Type |
Vacuum Fluorescent Display (VFD) |
|||||
|
Display Refresh Rate |
5 times / second, |
|||||
|
Std. Serial Interface |
RS-232C Interface / WinCT software included |
|||||
|
Weighing Pan |
85 mm / 3.5 “ dia
round pan |
|||||
|
External |
100g 50g |
200g 100g |
300g 200g 100g |
1000g 500g |
2000g 1000g |
3000g 2000g 1000g |
|
Power Consumption |
Approx. 11VA (supplied to the AC Adaptor) |
|||||
|
External Dimensions |
193 (W) x 262.5 (D) x 84.5 (H) mm |
|||||
